Quick Details

  • Condition: New
  • Power Type: Electric
  • Place of Origin: Shandong, China (Mainland)
  • Brand Name: Yueshou
  • Model Number: HZS75
  • Power(W): 105KW
  • Dimension(L*W*H): 30m*12m*17m
  • Weight: 33 tons
  • Certification: CE ISO GOST CCC
  • Warranty: 12 Month
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Productivity: 75 m3/h
  • control system: automatic/manual/fully computer control

Packaging & Delivery

Packaging Details 7 units 40HQ containers
Delivery Time within 20 days after receiving the deposit









HZS75 concrete mixing plant specification:
Main features

1) Good mixing performance

Our concrete batching plant adopts JS or YJS model of mixers self-designed by our company. All the mixing blades and                                                                                                 liners are made from wear-resistant cast iron with well-designed angle,so the mixer can achieve a good performance within a    short time and has a long service life.
2).Environmental friendly design
The main tower are decorated with color-coated corrugated steel board or sandwich board (Optional), dust remover is installed inside the main tower. For the sake of good working environment, every link of HZS series concrete batching plant designed by our company where dust tends to spill over is tightly enclosed. Both the mixer’s upper cover and the dust flue of powder measuring bin are conected with the automatic dust remover inside the main tower. The powder collected by dust remover can be conveniently recycnled. This series of concrete is up to the national environmental standard.

3).Monitoring system (Optional)
Monitoring system is optional for the users. With it the operators can easily perceive the location of concrete truck and the dumping of concrete, so it becomes more convenient to produce and raise the productivity.
4).Advanced electric control and management system
Our product adopts Siemens PLC control system and the main electronic components are imported, Siemens brand or Schneider brand. It can be operated both automatically and manually.
5).Beautiful structure
This plant has a reasonable layout and is ingeniously designed. It is firm &strong and easily detached &assembled& transported by containers.



6

Theoretical productivity

75m3/h

7

Dumping height

3.8m

8

Total power

105kw (without screw conveyor)

9

Total weight

33t(without powder silo and screw conveyor)

10

Floor area

30m*12m

11

Mixing system

Mixer

Power

Charging capacity

Discharging capacity



JS1500

30*2kw

2400L

1500L

12

Aggregate weighing system

Volume of aggregate bin

Volume of weighing hopper

Power of electric drum

Metering accuracy



15m3×4

1400L×4

7.5kw

±2%

13

Elevating system

Volume of elevating hopper

Windlass power



2400L

22kw

14

Cement weighing system

Volume of weighing hopper

Metering range

Metering accuracy



700L

0-700 kg

≤±1%

15

Fly ash weighing system



Volume of weighing hopper

Metering range

Metering accuracy



400L

0-360kg

≤±1%

16

Water weighing system

Volume of water scale

Pump power

Metering accuracy



500L

4 kw

≤±1%

17

Liquid additive weighing system

Volume of additive scale

Volume of additive tank

Pump power

Metering accuracy



40L

2m3

0.75kw

≤±1%

18

Pneumatic system

Compressor power:11kw

19

Screw conveyor

Model

273

219

168





Capacity

65t/h

45t/h

25t/h





Power

15 kw

11 kw

7.5 kw

20

Powder silo

50t,100t,150t,200t,300t

21

Operation room

6m2
